MODEL
|
HI500
|
HI1000
|
HI1500
|
HI2500
|
HI3500
|
HI5000
|
|
DC INPUT
|
|
Nominal input voltage
|
12 V
|
24 V
|
|
DC input voltage range
|
10 V ~ 15 V
|
20 V ~ 30 V
|
|
AC INPUT
|
|
Bypass voltage
|
0 ~ 264 Vac for 220 Vac / 230 Vac / 240 Vac,
0 ~ 132 Vac for 100 Vac / 110 Vac / 115 Vac / 120 Vac
|
|
AC voltage
|
150 ~ 282 Vac for 220 Vac, 156 ~ 294 Vac for 230 Vac, 163 ~ 307 Vac for 240 Vac,
68 ~ 128 Vac for 100 Vac, 75 ~ 141 Vac for 110 Vac, 79 ~ 148 Vac for 115 Vac, 82 ~ 154 Vac for 120 Vac.
|
|
Frequency
|
50 Hz / 60 Hz (auto-sense & settable: 5% ~ 15%, default 15%),
42.5 ~ 57.5 Hz for 50 Hz, 51 ~ 69 Hz for 60 Hz
|
|
Input voltage of generator
|
99 ~ 282 Vac for 220 Vac, 104 ~ 294 Vac for 230 Vac, 108 ~ 307 Vac for 240 Vac,
45 ~ 128 Vac for 100 Vac, 50 ~ 141 Vac for 110 Vac, 52 ~ 148 Vac for 115 Vac, 54 ~ 154 Vac for 120 Vac.
|
|
Input frequency of generator
|
40 ~ 70 Hz
|
|
Input power limitation
|
Rated power 10% ~ 150%, regulating step 10%, default 120%
|
|
OUTPUT
|
|
DC mode output voltage
|
220 Vac / 230 Vac / 240 Vac ± 5% or 100 Vac / 110 Vac / 115Vac / 120 Vac ± 5% (settable)
|
|
AC mode output voltage
|
174 ~ 242 Vac for 220 Vac, 182 ~ 253 Vac for 230 Vac, 190 ~ 264 Vac for 240 Vac,
79 ~ 109 Vac for 100 Vac, 87 ~ 121 Vac for 110 Vac, 93 ~ 125 Vac for 115 Vac, 95 ~ 133 Vac for 120 Vac.
|
|
Nominal output frequency
|
50 Hz / 60 Hz ± 0.3 (auto-sense & settable)
|
|
Output waveform
|
Pure sine wave
|
|
Output power
|
300 W
|
600 W
|
1000 W
|
1600 W
|
2500 W
|
3500 W
|
|
Efficiency
|
Max. 95% (mains mode); Max. 80% (inverter mode)
|
|
ECO mode
|
Settable, load < 3%, enter in 80 s
|
|
No-load shutdown
|
Settable, time can be set (1 ~ 99 min), load can be set (3% ~ 50%)
|
|
Transfer time
|
≤ 10 ms
|
≤ 15 ms
|
|
Power factor
|
0.6
|
|
THDV
|
< 5% (linear load)
|
|
Inductive load
|
Yes
|
|
Motor load
|
Yes
|
|
Rectifier load
|
Yes
|
|
Overload
|
Mains mode: 110% for 120 s, 125% for 60 s, 150% for 10 s (switch to bypass)
Inverter mode: 110% for 60 s; 125% for 10 s; 150% for 10 s (shut down)
|
|
BATTERIES
|
|
Charging current (selectable)
|
Default 10 A
|
Default 20 A, regulating step 1 A (< 10 A) / 5 A (> 10 A)
|
|
Max. 15 A
|
Max. 30 A
|
Max. 40 A
|
Max. 40 A
|
Max. 50 A
|
Max. 60 A
|
|
Equalizing charge voltage
|
Single battery 14.4 Vdc (default), 13.6 ~ 15 Vdc adjustable
|
|
Floating charge voltage
|
Single battery 13.7 Vdc (default), 13.2 ~ 14.6 Vdc adjustable
|
|
Charge mode
|
3 stage charge mode
|
|
DOD
|
Single battery 10.8 Vdc (default), 9.6 ~ 13 Vdc settable
|
|
EOD
|
Single battery 10.2 Vdc (default), 9.6 ~ 11.5 Vdc adjustable
|
|
Reverse warning
|
Buzzer
|
|
MPPT MODULES (OPTIONAL)
|
|
Model
|
10 A / 20 A / 30 A / 40 A
|
/
|
|
Max. PV input voltage (Voc)
|
40V
|
60V
|
/
|
|
PV optimum operating voltage (Vmp)
|
18V ~ 32V
|
29V ~ 48V
|
/
|
|
Max. PV power
|
120W / 240W / 360W / 480W
|
240W / 480W / 720W / 960W
|
/
|
|
DC MODULES (OPTIONAL)
|
|
Model
|
5V (2A), 9V / 12V (1A), 15V / 24V (1A), 12V / 24V (10A)
|
|
OTHERS
|
|
Protections
|
Overload – short-circuit – overvoltage – undervoltage – overcharge – overtemperature – excessive low battery
|
|
Human-machine interface
|
LCD & BUZZER
|
|
Operating temperature
|
0℃ ~ 40℃
|
|
Operating humidity
|
Relative humidity ≤ 93%
|
|
Net weight (kg)
|
8.0
|
10.9
|
14.0
|
18.0
|
32.0
|
36.0
|
|
Gross weight (kg)
|
9.0
|
11.9
|
15.0
|
19.0
|
34.0
|
38.0
|
|
Dimensions (W × D × H) (mm)
|
280 × 258 × 120
|
293 × 280 × 160
|
302 × 479 × 209
|
|
Packaged dimensions (W × D × H) (mm)
|
330 × 352 × 200
|
370 × 355 × 235
|
353 × 582 × 287
|
